Technical Partner Brief

Engineering a new energy paradigm

H2Phlo combines a PEM electrolyzer, solid‑state metal‑hydride hydrogen storage, and a high‑efficiency fuel cell into a single residential unit. The system is AI‑driven, grid‑aware, and designed for rapid OEM integration.

System Architecture

Four‑layer modular design

⚡
PEM Electrolyzer
High‑current, low‑voltage polymer electrolyte membrane cell that splits water at >80% efficiency. Scalable stack up to 5 kW for residential solar integration.
🧱
Solid‑State Metal‑Hydride Tank
Low‑pressure alloy absorbs H₂ at ambient temperature, achieving 5 kg storage density with <1% leakage over 12 months.
🔋
PEM Fuel Cell
Converts stored hydrogen back to AC power at 48 V, 95% round‑trip efficiency. Integrated inverter provides grid‑compatible 120/240 V output.
🤖
AI Energy Orchestrator
Edge‑ML model predicts optimal electrolysis windows, balances grid tariffs, and manages load‑shifting for EV charging and home loads.
☀ Solar / Grid Input Power 5 kW ⚡ PEM Electrolyzer H₂O → H₂ + O₂ · 82% H₂ 🛢 Metal-Hydride Tank 5 kg H₂ · 140 kWh <0.5% / month loss H₂ 🔋 PEM Fuel Cell H₂ + O₂ → AC · 95% eff. AC 🏠 Home + EV 120 / 240 V output AI Energy Orchestrator Edge-ML · tariff aware · solar forecast · load shifting byproduct: H₂O vapor only
Technical Specs

Key performance parameters

ParameterValue
Electrolyzer Power5 kW (peak)
Electrolyzer Efficiency≈ 82 %
Hydrogen Storage Capacity5 kg (≈ 140 kWh)
Storage Leakage<0.5 % per month
Fuel Cell Output3 kW continuous, 5 kW peak
Round‑Trip Efficiency≈ 95 %
Operating Temperature5 °C – 45 °C
Dimensions (HxWxD)45 cm × 30 cm × 30 cm
Weight35 kg
Safety CertificationsUL 9540A, IEC 62282‑3‑100, NFPA 2
Warranty10 years hardware, 5 years fuel‑cell stack
Get Involved

Partner with H2Phlo

We are actively seeking OEMs, component suppliers, and system integrators to accelerate mass production. Join us in redefining residential energy storage.

Email the Team →

The Team

Meet the founders.

Three UT Austin alumni building the future of residential energy independence.

Luke Wade
Luke Wade
Co-Founder · CEO
daddy

UT Austin Plan II Honors ’11. Senior Sales Engineer at Insightly (Unbounce). A decade of enterprise SaaS GTM experience turning complex technical systems into compelling customer value.

James Bayless
James Bayless
Co-Founder · CTO
Head of HR

UT Austin BS Mechanical Engineering ’11, TCU Neeley MBA ’20. 5+ years at BHP Billiton Petroleum from engineer to drilling supervisor on deepwater unconventional wells. Precision built under pressure.

Brian McDonald
Brian McDonald
Co-Founder · CPO
Secretary to the CEO

UT Austin BS ME (Tau Beta Pi), Stanford MS ME ’14 — energy systems & heat transfer. VP Product at Magna Imperio Systems where he commercialized the world’s first industrial-scale electrochemical desalination system. Dir. of HW Engineering at Pattern Bioscience.
